| Specification |
44/130 |
88/200 |
| Trough Depth |
44 mm |
88 |
| Pitch Centre to Centre |
130 mm |
200 |
Sheet Width Feed
|
1220 mm |
915 |
Covered Width
|
910 mm |
600 |
| Length |
Up to 12 Meters |
upto 10 meters |
| Thickness |
0.40 mm to 3.00 mm |
0.6 to 100 MM |
|
Material |
Yield |
Colour |
Coating |
Pre-painted Galvanised Steel |
220 - 350 Mpa |
As per shade card |
120 to 275 gsm |
Pre-Painted Galvalume Steel |
350-550 Mpa |
As per shade card |
150 gsm |
Pre-Painted Aluminum |
180 Mpa |
As per shade card |
In its Alloy form |
Cold Rolled Steel |
220Mpa |
Bare |
Bare |
|
