| Section |
Depth D |
Thickness t |
Lip 1-2 |
Falnge 1 |
Flange 2 |
Area cm2 |
Wt Kg/M |
1XX cm2 |
1yy cm2 |
2xx cm2 Top |
2xx cm2 Bottom |
| 90/200 90/230 |
90
90 |
2.0
2.3 |
20 20 |
60
60 |
52.5 52.5 |
4.23 4.82 |
3.37 3.78 |
53.77 60.54 |
28.71 32.07 |
12.38 13.94 |
11.55 13.00 |
| 110/200 110/250 |
110 110 |
2.0
2.5 |
20 20 |
60
60 |
52.5 52.5 |
4.64 5.70 |
3.64 4.47 |
86.20 104.30 |
28.73 34.20 |
16.19 19.20 |
15.19 18.39 |
| 130/200 130/250 |
130 130 |
2.0
2.5 |
20 20 |
60
60 |
52.5 52.5 |
5.04 6.20 |
3.95 4.87 |
127.90 155.20 |
28.75 34.22 |
20.27 24.61 |
19.12 23.19 |
| 150/200 150/250 |
150 150 |
2.0
2.5 |
20 20 |
60
60 |
52.5 52.5 |
5.74 7.07 |
4.50 5.55 |
196.10 238.90 |
41.61 49.78 |
26.84 32.70 |
25.49 31.04 |
| 170/200 170/250 |
170 170 |
2.0
2.5 |
20 20 |
60
60 |
52.5 52.5 |
6.14 7.57 |
4.82 5.94 |
263.50 321.40 |
41.63 49.80 |
31.77 38.76 |
30.27 36.92 |
| 190/250 190/250 |
190 190 |
2.0
2.5 |
20 20 |
60
60 |
52.5 52.5 |
6.54 8.07 |
5.13 6.34 |
343.10 409.10 |
41.64 49.82 |
36.96 45.16 |
35.32 43.13 |
| 210/200 210/250 |
210 210 |
2.0
2.5 |
20 20 |
60
60 |
52.5 52.5 |
6.94 8.57 |
5.45 6.73 |
435.90 533.00 |
41.65 49.83 |
42.42 57.88 |
40.64 49.69 |
| 230/200 230/250 |
230 230 |
2.0
2.5 |
20 20 |
60
60 |
52.5 52.5 |
7.34 9.07 |
5.76 7.12 |
542.47 663.99 |
41.66 49.85 |
48.15 58.94 |
46.23 56.58 |
|
|
